ZZ® G50
For moving joints in solid walls and floors for temporary or permanent preservation of fire resistance.
System information
| Test norm | EN 1366-4 |
| Approval Number | ETA-12-0119 |
| Fire resistance class | E, EI |
| Fire resistance duration [min] | 30, 60, 90, 120 |
| Seal type | Joint seal |
| Seal opening | joint |
| approved components | rigid wall, rigid floor |
System components
| Designation | Art.-Nr. | VE | ||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
ZZ® 530 Fire Protection Joint Seal show variants
| ||||||||||||||||||||||||||||||||||||||
Detailinformationen
- Downloads
- Description
Details
For moving joints in solid walls and floors for temporary or permanent preservation of fire resistance.
- Additional Information
Additional Information
Suitable for - Joint width up to 75 mm
- Up to 25 % movement capability
- One product solution and application from one side
Approved penetrating elements - Parting and expansion joints of large-surface solid components with a fire resistance class up to EI 120.
- One single product solution ensures effective fire protection.
