ZZ® G50

For moving joints in solid walls and floors for temporary or permanent preservation of fire resistance.

Test norm EN 1366-4
Approval Number ETA-12-0119
Fire resistance class E, EI
Fire resistance duration [min] 30, 60, 90, 120
Seal type Joint seal
Seal opening joint
approved components rigid wall, rigid floor

System components

DesignationArt. no.PU
ZZ® 530 Fire Protection Joint Seal show variants
DesignationDiameter [mm]Art. no.PU
ZZ® 530-16 Fire Protection Joint SealØ 16B08V20-000120
ZZ® 530-24 Fire Protection Joint SealØ 24B08V20-000220
ZZ® 530-30 Fire Protection Joint SealØ 30B08V20-000320
ZZ® 530-39 Fire Protection Joint SealØ 39B08V20-000420
ZZ® 530-49 Fire Protection Joint SealØ 49B08V10-000110
ZZ® 530-60 Fire Protection Joint SealØ 60B08V08-00018
ZZ® 530-70 Fire Protection Joint SealØ 70B08V06-00016
ZZ® 530-80 Fire Protection Joint SealØ 80B08V04-00014
DesignationMax. joint widthArt. no.PU
ZZ® 530-16 Fire Protection Joint Seal13B08V20-000120
ZZ® 530-24 Fire Protection Joint Seal21B08V20-000220
ZZ® 530-30 Fire Protection Joint Seal27B08V20-000320
ZZ® 530-39 Fire Protection Joint Seal35B08V20-000420
ZZ® 530-49 Fire Protection Joint Seal45B08V10-000110
ZZ® 530-60 Fire Protection Joint Seal55B08V08-00018
ZZ® 530-70 Fire Protection Joint Seal65B08V06-00016
ZZ® 530-80 Fire Protection Joint Seal75B08V04-00014

Detailed information

Downloads

Download all

Description

For moving joints in solid walls and floors for temporary or permanent preservation of fire resistance.

Additional Information

Suitable for
  • Joint width up to 75 mm
  • Up to 25 % movement capability
  • One product solution and application from one side
Approved penetrating elements
  • Parting and expansion joints of large-surface solid components with a fire resistance class up to EI 120.
  • One single product solution ensures effective fire protection.
Additional custom solutions are permissible for other requirements such as appearance and humidity.
